Published: July 22, 2012

Brazil 2012 Fieldwork Diary Entry 6: Sharks Patrol These Waters

Ken Angielczyk, MacArthur Curator of Paleomammalogy and Section Head, Negaunee Integrative Research Center

In my last entry, I noted that geological evidence suggests that some of the rocks that we're working in were formed near the shore of an inland sea, but that the environment became increasingly terrestrial as time passed, with some of the younger rocks representing sand dunes. Over the past two days, most of the fossils we discovered were preserved in the rocks that formed along the shoreline and are the remains of aquatic animals.

Fossil spine from a large xenacanth shark embedded in rocks of the Pedra de Fogo Formation. In life, the spine was located near the animal's head. Scale bar is in centimeters. Photo by Ken Angielczyk.

In my last entry, I noted that geological evidence suggests that some of the rocks that we're working in were formed near the shore of an inland sea, but that the environment became increasingly terrestrial as time passed, with some of the younger rocks representing sand dunes. Over the past two days, most of the fossils we discovered were preserved in the rocks that formed along the shoreline and are the remains of aquatic animals.

The most impressive of these animals are the large xenacanth sharks (an extinct group of sharks that were common in the Permian). Typically, very little of their skeletons are preserved because they were mostly made of cartilage, a material that decays before it can be fossilized. Most of what we find of them are large spines that were made of a mineralized tissue similar to bone, and which have a distinctive pattern of ornamentation. Last year we found a few of these spines, and the one in the picture above was found yesterday (April 15) by Christian Kammerer. We also found teeth of these sharks last year, but so far haven't discovered any this year.

A second denizen of the Pedra de Fogo are lungfish. Very few fossils of lungfish have been discovered previously in these rocks, but yesterday Jose (one of our drivers who is also a good fossil finder) discovered a very large lungfish tooth plate. Unlike us, lungfish only have four teeth in their mouths, and they have a very distinctive shape that makes them easy to recognize. We found additional lungfish toothplates today (April 16), although they were much smaller and may represent juvenile animals. Although rare today, lungfish have a long history in the fossil record, and are important in evolutionary studies because they are closely related to terrestrial vertebrates.

Lungfish toothplate from the Pedra de Fogo Formation. This is one of the first lungfish fossils to be discovered in these rocks, making it an important specimen. Scale bar is in centimeters. Photo by Ken Angielczyk.

Besides lungfish, we found members of the other main group of fish, the ray-finned fish. Several exciting specimens that we discovered yesterday that represent this group are jaws with teeth preserved. Today, in rocks that are slightly younger and probably formed in a more terrestrial environment, we found other specimens of ray-finned fish, but these were still articulated (i.e., the parts of the skeleton were still attached as in life). Martha Richter has seen similar specimens from that locality, and thinks they are early representatives of a group of ray-finned fish that were more common and diverse in the Mesozoic Era of Earth history (about 205 to 65 million years ago).

Jaw of a ray-finned fish showing teeth. Scale bar is in centimeters. Photo by Ken Angielczyk.

You may have noticed that I haven't mentioned any synapsid specimens yet. So far we haven't discovered any, but we have found fragmentary remains that seem to represent the archaic amphibians (or temnospondyls) that were common during the Permian Period. Many temnospondyl bones have a distinctive pattern of sculpturing on them that helps to differentiate them from similar-looking fish bones that we also find in these rocks. We only discovered a few of these bones so far, but they are important because they represent terrestrial vertebrates.

A probable skull bone from a temnospondyl amphibian. The sculpturing of the bone helps to differentiate it from similar fish bones found in the same rocks. Scale bar is in centimeters. Photo by Ken Angielczyk.

We'll carry on our search for the elusive synapsids tomorrow, but the fossils we collected so far are helping us paint a more complete picture of the animals that were living in the Parnaíba Basin during the Permian.


Ken Angielczyk
MacArthur Curator of Paleomammalogy and Section Head

I am a paleobiologist interested in three main topics: 1) understanding the broad implications of the paleobiology and paleoecology of extinct terrestrial vertebrates, particularly in relation to large scale problems such as the evolution of herbivory and the nature of the end-Permian mass extinction; 2) using quantitative methods to document and interpret morphological evolution in fossil and extant vertebrates; and 3) tropic network-based approaches to paleoecology. To address these problems, I integrate data from a variety of biological and geological disciplines including biostratigraphy, anatomy, phylogenetic systematics and comparative methods, functional morphology, geometric morphometrics, and paleoecology.

A list of my publications can be found here.

More information on some of my research projects and other topics can be found on the fossil non-mammalian synapsid page.

Most of my research in vertebrate paleobiology focuses on anomodont therapsids, an extinct clade of non-mammalian synapsids ("mammal-like reptiles") that was one of the most diverse and successful groups of Permian and Triassic herbivores. Much of my dissertation research concentrated on reconstructing a detailed morphology-based phylogeny for Permian members of the clade, as well as using this as a framework for studying anomodont biogeography, the evolution of the group's distinctive feeding system, and anomodont-based biostratigraphic schemes. My more recent research on the group includes: species-level taxonomy of taxa such as Dicynodon, Dicynodontoides, Diictodon, Oudenodon, and Tropidostoma; development of a higher-level taxonomy for anomodonts; testing whether anomodonts show morphological changes consistent with the hypothesis that end-Permian terrestrial vertebrate extinctions were caused by a rapid decline in atmospheric oxygen levels; descriptions of new or poorly-known anomodonts from Antarctica, Tanzania, and South Africa; and examination of the implications of high growth rates in anomodonts. Fieldwork is an important part of my paleontological research, and recent field areas include the Parnaíba Basin of Brazil, the Karoo Basin of South Africa, the Ruhuhu Basin of Tanzania, and the Luangwa Basin of Zambia. My collaborators and I have made important discoveries in the course of these field projects, including the first remains of dinocephalian synapsids from Tanzania and a dinosaur relative that implies that the two main lineages of archosaurs (one including crocodiles and their relatives and the other including birds and dinosaurs) were diversifying in the early Middle Triassic, only a few million years after the end-Permian extinction. Finally, the experience I have gained while studying Permian and Triassic terrestrial vertebrates forms the foundation for work I am now involved in using models of food webs to investigate how different kinds of biotic and abiotic perturbations could have caused extinctions in ancient communities.

Geometric morphometrics is the basis of most of my quantitative research on evolutionary morphology, and I have been using this technique to address several biological and paleontological questions. For example, I conducted a simulation-based study of how tectonic deformation influences our ability to extract biologically-relevant shape information from fossil specimens, and the effectiveness of different retrodeformation techniques. I also used the method to address taxonomic questions in biostratigraphically-important anomodont taxa, and I served as a co-advisor for a Ph.D. student at the University of Bristol who used geometric morphometrics and finite element analysis to examine the functional significance of skull shape variation in fossil and extant crocodiles. Focusing on more biological questions, I am currently working on a large geometric morphometric study of plastron shape in extant emydine turtles. To date, I have compiled a data set of over 1600 specimens belonging to nine species, and I am using these data to address causes of variation at both the intra- and interspecific level. Some of the main goals of the work are to examine whether plastron morphology reflects a phylogeographic signal identified using molecular data in Emys marmorata, whether the "miniaturized" turtles Glyptemys muhlenbergiiand Clemmys guttata have ontogenies that differ from those of their larger relatives, and how habitat preference, phylogeny, and shell kinesis affect shell morphology.

A collaborative project that began during my time as a postdoctoral researcher at the California Academy of Sciences involves using using models of trophic networks to examine how disturbances can spread through communities and cause extinctions. Our model is based on ecological principles, and some of the main data that we are using are a series of Permian and Triassic communities from the Karoo Basin of South Africa. Our research has already shown that the latest Permian Karoo community was susceptible to collapse brought on by primary producer disruption, and that the earliest Triassic Karoo community was very unstable. Presently we are investigating the mechanics that underlie this instability, and we're planning to investigate how the perturbation resistance of communities as changed over time. We've also experimented with ways to use the model to estimate the magnitude and type of disruptions needed to cause observed extinction levels during the end-Permian extinction event in the Karoo. Then there's the research project I've been working on almost my whole life.

Morphology and the stratigraphic occurrences of fossil organisms provide distinct, but complementary information about evolutionary history. Therefore, it is important to consider both sources of information when reconstructing the phylogenetic relationships of organisms with a fossil record, and I am interested how these data sources can be used together in this process. In my empirical work on anomodont phylogeny, I have consistently examined the fit of my morphology-based phylogenetic hypotheses to the fossil record because simulation studies suggest that phylogenies which fit the record well are more likely to be correct. More theoretically, I developed a character-based approach to measuring the fit of phylogenies to the fossil record. I also have shown that measurements of the fit of phylogenetic hypotheses to the fossil record can provide insight into when the direct inclusion of stratigraphic data in the tree reconstruction process results in more accurate hypotheses. Most recently, I co-advised two masters students at the University of Bristol who are examined how our ability to accurately reconstruct a clade's phylogeny changes over the course of the clade's history.
